JIS G 3116 SG255 gas cylinder hot rolled steel plate Mechanical property steel plate

JIS G 3116 SG255 gas cylinder <a href=http://www.steel-plate-sheet.com/Sellinglist/ASTM-A517-Gr-70-Hot-rolled-steel-plate.html target=_blank class=infotextkey>Hot rolled steel plate</a> Mechanical property



JIS G3116 SG255 gas cylinder hot rolled steel plate is a kind of common steel plates mainly used for pressure vessels . G 3116 SG255 steel plate with the tensile strength of 400 Mpa and the yield strength of 255 Mpa.JIS G3116 SG255 steel plate is in Japanese standard JIS G3116 . SG255, SG295, SG325, SG365 are series steel grades or levels of JIS G3116 . JIS G3116 SG255, SG295, SG325, SG365 used to fabricate low temperature pressure vessels like gas cylinder.
JIS G 3116 SG255 gas cylinder hot rolled steel plate Chemical composition(%):
C≤0.20     Mn≥0.30  P≤0.040  S≤0.040
Dimension range : 1.5mm -5mm x 400mm-2000mm x 1000mm-18000mm
Delivery time : Promptly ( Stock) or 10-40 days (Production)
Stock : Available
MTC: Available
Payment Term : T/T or L/C At sight .
JIS G 3116 SG255 gas cylinder hot rolled steel plate Mechanical property:

Symbol

Yield point or pro-of stress

N/mm2 (min)

Tensile strength

-N/mm2 min

Elongation %

min

Tensile test -piece Bendability

Bending

-Angle

Inside radius Test piece
SG255 255 400 26 NO.5 in rolling-direction 180°

Thickness x 1.0

  Thickness x 1.5

No.3 in rolling-direction
Bebon International always uphoid the purpose of mutural benefit,we always offer preferential price and comprehensive services of JIS G 3116 SG255 gas cylinder hot rolled steel plate .If you place an order of JIS G 3116 SG255 steel plate to us,we will give you a satisfactory answer.
